Панель управления P6

The P6 control panel is a cutting-edge intelligent control hub, delivering a seamlessly integrated experience. Featuring a 4-inch IPS full-screen display with a 720*720 RGB resolution, the P6 perfectly combines stylish design with powerful functionality. Powered by the powerful Amlogic S905D3 quad-core Cortex-A55 processor, running Android 9.0, it supports WiFi, Bluetooth, and optional Zigbee connectivity, making it a versatile hub for controlling smart devices. The panel features a capacitive touchscreen, dual digital microphones, a 1W built-in cavity speaker, and advanced features such as AI voice algorithms and a night light LED. Its low power consumption and durable design make the P6 an ideal choice for intelligent control, offering both online and offline voice control. It supports fast scene switching, volume control, playback control, and extensive custom settings, all for ease of use. Paired with other Soundfit audio products, it can meet diverse application needs.

Поделиться:

  • P6 Control Panel

ОПИСАНИЕ ПРОДУКТА

Характеристики продукта

  • Core Processor: Amlogic S905D3, Quad-Core Cortex-A55
  • Capacitive touchscreen control with standard TCP/IP protocol transmission, no PC configuration required
  • Powered by PoE or 24V adapter, with hot backup
  • Network control processor, unlimited distance
  • 4-inch IPS slim-edge, ultra-thin full-screen operation
  • Supports fast scene switching, volume control, playback control, and extensive custom settings for ease of use.

ПАРАМЕТРЫ ПРОДУКТА

Отображать 4-inch IPS full-screen display, 720×720 RGB resolution
Touchscreen Fully laminated capacitive touchscreen
CPU Amlogic S905D3, quad-core Cortex-A55
RAM 1GB LPDDR4
Memory 8GB EMMC
Wi-Fi AP6236A (IEEE 802.11b/g/n)
Bluetooth BT 4.2
Zigbee TYZS13 (reserved)
AI Voice Algorithm Interactive query algorithm
RTC Reserved
Operating System Android 9.0
Buttons Reset pinhole
МИК Dual digital microphones
Спикер Built-in 1W cavity speaker
ВЕЛ Night light reminder
Sensor VL6180X three-in-one proximity, light, and infrared sensor (reserved)
Internal Interface USB 2.0 port (1); Debug serial port (1); RS485: 1 (reserved); RJ45: 1 RJ45 port
Рабочая температура -20°C, +60°C
Рабочая влажность 90-95% RH
Standby Power Consumption ≤0,5 Вт
Operating Power Consumption 3W
Power Input 5V 1A input on panel, 24V power supply for the entire unit
Accessories Mounting screws, instruction manual
Размеры 86*86*38mm
Масса 235g

СЦЕНАРИЙ ПРИМЕНЕНИЯ

СВЯЗАННЫЕ СКАЧИВАНИЯ

Имя РазмерВремяСкачать
P6 Control Panel Datasheet 2025-10-22
